ASCO RedHat II 3-Way Solenoid Valves — 2-Unit Lot
ASCO RedHat II EVX8316G382MF15444 24 VDC 3-Way Solenoid Valves — 2-Unit Lot
Description
This offering is for two matching ASCO RedHat II EVX8316G382MF15444 solenoid valves. The nameplate records 24 VDC, 1.4 W, 3/8 in. pipe connection, external piloting, and a 40–150 psi marking. The physical example valve is protected by a red port cap and is supplied with multicolour flying leads.
The exact ASCO configuration is published as a stainless-steel, normally closed, 3-way/2-position, low-power Series 8316 solenoid valve for air or inert-gas service. It has three 3/8 in. female threaded ports, 24 VDC input, and 1.4 W power consumption. Emerson describes the ASCO Series 316/8316 as a high-flow 3-way solenoid-valve family that can be used to pilot large actuators and provide quick closure of large control valves.
Verified Identification and Published Reference Data
| Specification | Detail |
| Lot quantity | 2 matching valves |
| Manufacturer / series | ASCO RedHat II; Series 8316 / 316 |
| Valve catalog number | EVX8316G382MF15444 |
| Electrical supply | 24 VDC |
| Nameplate coil power | 1.4 W |
| Valve function | 3-way / 2-position; normally closed |
| Port configuration | Three 3/8 in. female threaded ports |
| Published media | Air / inert gas |
| Published operating-pressure range | 15–150 psi for air/inert gas |
| Nameplate pilot arrangement | External pilot |
| Nameplate air marking | Air: 15–150 psi when externally piloted |
| Published body material | Stainless steel |
| Published seal material | NBR |
| Visible serial number | T24101817 on photographed example valve |
| Nameplate rebuild-kit number | 316982 |
