Bulk Inventory List Coupling OEM Spare Parts Package (22-Item Lot)
Supporting Documents (1)
library_books
Offered for sale is a package of 22 line items (33 total units) of OEM and OEM-equivalent spare parts for industrial couplings.
Description
Offered for sale is a package of 22 line items (33 total units) of OEM and OEM-equivalent spare parts for industrial couplings. Parts were sourced from major OEMs and authorized distributors, and have been stored unused in an indoor warehouse environment.
The package covers a range of coupling types including disc couplings, gear spacer couplings, fluid couplings, and flexible element couplings. Brands represented include Rexnord Thomas, Koppers/Kop-Flex, Voith, Metastream, and Wichita. A complete inventory manifest is attached.
Applicable Equipment
| Brand | Model / Type | Notes |
| Rexnord Thomas | No. 262 Series 63, No. 600 Series 52 | High-speed and low-speed disc couplings |
| Koppers / Kop-Flex | Fast's High Performance Gear Spacer (Size 5 & 7), Disc Coupling #253RM, Model B Full Flex (Size 1-1/2) | 12" DBSE, finished bore, keyway |
| Voith | Fluid Coupling Type 274DT | Sealed bearing, continuous operation |
| Metastream | TSCS-0350, TSCS-0230, TSCS-0135, TSCS-0013 | Transmission units and large hubs |
| Wichita | Mesur-Fil HCM, Size 12.4 | Fluid coupling |
| Rexnord Omega | ES50 | Spacer element |
| Flexible Cam | ENK-200SX | Bore 1.625" dia, motor shaft |
Highlights
Rexnord Thomas: The package includes two complete coupling assemblies — a high-speed disc coupling (No. 262 Series 63, per DWG# D046769) and a low-speed disc coupling (No. 600 Series 52, per DWG# 34403) — along with two spare disc packs for each (P/Ns CO 28933 and 10959 respectively), a weight balance locknut set (P/N 008372), a weight balance bolt set (P/N 008361), and one Rexnord Omega ES50 spacer element.
Koppers / Kop-Flex: Two complete Fast's High Performance Gear Spacer Couplings — Size 7 (low speed) and Size 5 (low speed) — both for 12" DBSE with finished bore, keyway, and balance. Also included are two flange accessory sets for Kop-Flex disc coupling #253RM (P/N WA82271-36BR with 36 bolts & nuts, and P/N WA82271-22BR with 22 bolts & nuts), and one complete Kop-Flex Model B Full Flex coupling (Type SB, Size 1-1/2, shrouded bolt).
Voith Fluid Couplings (Type 274DT): Six fluid coupling units suitable for continuous operation with sealed bearings, for ENK-SX coupling service (1.75" dia shaft). Also included are two MTS switch elements (P/N TCR11954250, 10 mm, 140°C) for the 274DT.
Metastream Transmission Units: Four Metastream transmission units and hubs across three sizes — two TSCS-0135 7" units (P/N TSCS-0135-0000-1778), one TSCS-0350 8-1/2" unit (P/N TSCS-0350-0100-2159), one TSCS-0013 4-3/8" unit (P/N TSCS-0013-0000-1111), and one TSCS-0230 large hub 7" spacer (P/N TSCS-0230-0066-1778).
Wichita Fluid Couplings: Three Wichita Mesur-Fil HCM fluid coupling assemblies, Size 12.4 (Assembly No. 6-612-003-000-0000).
Other: One flexible cam coupling ENK-200SX (bore 1.625" dia) and one custom-machined bottom coupling for crystallizer service (Coastal Machine Shop).
